   Product information:WHJ-D30 Precision potentiometer     Number of hits: 1802
WHJ-D30 Precision synthetic carbon film potentiometer

 WHJ4, WHJ-D30 precision synthetic film potentiometer
Characteristic profile:
Nominal resistance range: 1K ~ 100K.
Resistance tolerance: ±5% ± 10%
Rated power: 1W
With center tap, diameter 30mm
Maximum operating voltage: 250V
Mechanical life: 200000 turns
Linear accuracy: ± 0.1% to ± 0.5%
Mechanical angle: 360 degree continuous, effective electrical angle ±160
Axis end shape: ZS - 1
